[C302-WF] - Getting Started

[C302-WF] - Getting Started

Getting Started with your Candeo C302-WF

Download the Instruction Manual here:

C302-WF Instruction Manual

Wiring Instructions


Installation Instructions

Please follow the wiring instructions article linked above, and then using the screws included, attach the C302-WF to the backbox. Finally press the screw caps over the screws.
​

Factory Reset the Device

  1. To factory reset the switch press and hold the knob for 10 seconds.
  2. The light will blink twice to confirm a successful reset.

Pairing

Pairing to Smart Life - Method 1
Pairing to Smart Life - Method 2
Pairing to Smart Life - Method 1

  1. Prepare your smart phone.
    1. Install the Smart Life from your app store, and create an account if you do not already have one.
    2. Ensure that you have Bluetooth enabled on your smart phone.
  2. Factory reset the switch as detailed above.
  3. Open the Smart Life app and choose to add a new device with the (+) icon.
  4. Allow the app to scan for new devices.
  5. Once the new device has been discovered, select “Add”, and the (+) to add the Wi-Fi dimmer to your devices.
  6. Rename the device as you wish, and you can now control the switch via the Smart Life app.

If connection fails using the above method, please turn off Bluetooth on your phone, and follow method 2.

Pairing to Smart Life - Method 2

  1. Factory reset the switch as detailed above.
  2. Open the Smart Life app and choose to add a new device with the (+) icon.
  3. From the left hand device options, select “Lighting” and then choose “Light Source (Wi-fi)
  4. Follow the steps in the Smart Life app, indicating that the light is blinking slowly or breathing.
  5. Smart Life will find the switch, and allow you to add it to your devices.
  6. Rename the device as you wish, and you can now control the switch via the Smart Life app.


FAQs and Troubleshooting
